Monitoring a Terrarium With PRTG

Environmental monitoring

There are many consumer products that let you measure temperature and humidity, like OpenHAB or Domoticz, but none of these options really fulfilled Patrick's needs. Whether it was because of a Web interface that wasn't intuitive, or complicated ways to connect sensors, nothing appealed to him.

After some searching, he eventually found a WLAN switch module with connections for a temperature and humidity sensor (a Sonoff TH10). He then flashed it with Tasmota software so that he could integrate it into an MQTT-based sensor network. He used this solution with Domoticz, but was only moderately satisfied with it.

Then, one evening, it occurred to Patrick that maybe he could use PRTG to monitor the temperature and humidity of the terrarium, and so he sat down at his computer and got to work.

PRTG Network Terrarium Monitor

The Tasmota firmware that Patrick installed on the Sonoff TH10 allows him to query the current temperature and humidity values using an HTTP command. Patrick wrote a short JAVA program that queries these values, and prepares an XML output file that can be understood by PRTG.

In PRTG, Patrick uses the EXE/Script Advanced sensor to call the JAVA program every minute using a batch file. As an input argument, the batch file provides an IP address to the JAVA program (in this case, the IP address of the Sonoff TH10). This also means that the solution can be used for other devices, too, by changing the IP address.

The EXE/Script Advanced sensor then uses the XML file produced by the JAVA program to display the measured data in two channels: Temperature and Humidity.

Here's an example of the graph that the whole process generates:

Patrick can also set the sensor to provide him with "Warning" and "Error" notifications if the temperature and humidity values go too high or too low, and he can react to this data. So not only is Patrick utilizing PRTG to keep an eye on his home network, but he is also ensuring that Merlin feels comfortable in his terrarium. Everything from one app!

Sample JAVA code

Here's a sample of Patrick's JAVA program that is called by the EXE/Script Advanced sensor.

package tasmotareader;

import java.io.BufferedReader;
import java.io.IOException;
import java.io.InputStreamReader;
import java.net.MalformedURLException;
import java.net.URL;
import java.util.logging.Level;
import java.util.logging.Logger;

/**
 * @author Patrick
 * @version 1.1
 */

public class TasmotaReader
{
    /**
     * @param args The Command Line Arguments
     */
    public static void main(String[] args)
    {
        // Start Building XML Response
        System.out.println("<prtg>");

        // Check Correct Number of Arguments Received
        if (args.length == 1)
        {
            // Number of Command Line Arguments Correct

            // Initialize IO
            BufferedReader in = null;

            // Do Or Do Not, There Is No Try...
            try
            {
                // Get IP from first Command Line Argument
                String IP = args[0];

                // Build URL from IP
                URL tasmotaURL = new URL("http://" + IP + "/cm?cmnd=status%2010");

                // Create IO to Read Answer
                in = new BufferedReader(
                    new InputStreamReader(tasmotaURL.openStream()));

                // Variable for Line-by-Line Reading of HTTP Response
                String inputLine;

                // Read HTTP Response until Values found or Response Ends
                while ((inputLine = in.readLine()) != null)
                {
                    // Search for Keyword
                    if (inputLine.startsWith("STATUS10"))
                    {
                        // Keyword found, Split String to Isolate Values
                        String[] splitStrings = inputLine.split("AM2301");
                        splitStrings = splitStrings[1].split(":");

                        // Split some more...
                        String sTemp = splitStrings[2].substring(0,4);
                        String sHumidity = splitStrings[3].substring(0,4);

                        // Continue building XML Response
                        // Add Temperature Channel
                        System.out.println("<result>");
                        System.out.println("<channel>Temperature</channel>\r\n"
                                + "<unit>°C</unit>\r\n<float>1</float>\r\n"
                                + "<value>" + sTemp + "</value>");
                        System.out.println("</result>");
                        // Add Humidity Channel
                        System.out.println("<result>");
                        System.out.println("<channel>Humidity</channel>\r\n"
                                + "<unit>%rH</unit>\r\n<float>1</float>\r\n"
                                + "<value>" + sHumidity + "</value>");
                        System.out.println("</result>");

                        // Leave While-Loop
                        break;
                    }
                }
                // Close IO
                in.close();

                // Finalize XML Response
                System.out.println("</prtg>");

                // Go Home Happy
                System.exit(0);
            }
            // URL Malformed Exception Handling
            catch (MalformedURLException ex)
            {
                // Write Error To XML Response
                System.out.println("<error>2</error>\r\n<text>Invalid URL - "
                        + ex.toString() + "</text>");
                System.out.println("</prtg>");
                // Go Home Sad
                System.exit(1);
            }
            // General IO Exception Handling
            catch (IOException ex)
            {
                // Write Error To XML Response
                System.out.println("<error>2</error>\r\n<text>I/O Exception - "
                        + ex.toString() + "</text>");
                System.out.println("</prtg>");
                // Go Home Sad
                System.exit(1);
            }
            finally
            {
                // Close IO Gracefully
                if (in != null)
                {
                    try
                    {
                        in.close();
                    }
                    catch (IOException ex)
                    {
                        // Exception While Trying to Gracefully Close IO
                        // Shall be Ignored Here
                        // Go Home Sad
                        System.exit(1);
                    }
                }
            }
        }
        // Number of Command Line Arguments Incorrect
        else
        {
            // Write Error To XML Response
            System.out.println("<error>2</error>\r\n<text>Invalid Arguments ("
                    + args.length + " args)</text>");
            System.out.println("</prtg>");
            // Go Home Sad
            System.exit(1);
        }
    }
}

Send us your use cases!

This isn't the first time PRTG helped keep an animal comfortable: way back in 2017, we wrote about Flash the turtle who had the temperature of its tank monitored.

Do you have cool use cases of PRTG? Then let us know in the comments below and you might be featured on our blog!
